Retaining Wall Design Settings Section
With the Retaining Wall Design Settings, the design parameters used in the Concrete Retaining Wall Design are determined. Concrete cover, maximum and minimum reinforcement interval, etc. parameters are determined from the Retaining Wall Design Settings window.
![](../__attachments/2378269148/image-20231107-121842.png?inst-v=5c738f36-5d0a-4235-b600-0cef56c14e9d)
Specifications |
---|
Concrete cover ![]() It is the distance from the center of gravity of the reinforcement to the outer face of the concrete. |
Min. tensile percentage ![]() In the tensile zone, give the minimum percentage value to be used in the rebar calculation. The entered value is multiplied by the sectional area and the rebar selection is made in a way that is not less than the result. |
Min. tensile interval ![]() In the tensile zone, give the smallest possible distance between two rebar bars. This value is taken into consideration in the selection of rebar. |
Max. tensile interval ![]() In the tensile zone, give the value of the greatest possible distance between two rebars. This value is taken into consideration in the selection of rebar. |
Min. transverse percentage ![]() Give the minimum percentage value to be used in horizontal rebars. The entered value is multiplied by the sectional area and the rebar selection is made in a way that is not less than the result. |
Min. transverse interval ![]() Give the smallest possible distance between two rebars for use in horizontal rebars. This value is taken into consideration in the selection of rebar. |
Max. transverse interval ![]() Give the maximum possible distance between two reinforcement bars to be used in horizontal reinforcements. This value is taken into consideration in the selection of reinforcement. |
Min. compression percentage ![]() In the pressure zone, give the minimum percentage value to be used in rebar calculation. The entered value is multiplied by the sectional area and the rebar selection is made in a way that is not less than the result. |
Min. compression interval ![]() Give the smallest possible distance between two reinforcing bars in the pressure zone. This value is taken into account in the selection of reinforcement. |
Max. compression interval ![]() Give the maximum possible distance between two reinforcing bars in the pressure zone. This value is taken into consideration in the selection of reinforcement. |
